TUF GAMING Z890-PRO WIFI
The ASUS TUF GAMING Z890-PRO WIFI combines the essential features of the Intel® Core™ Ultra Processors (Series 2) with robust durability and performance-focused engineering. Built with military-grade components, a reinforced power design, and comprehensive cooling, it ensures rock-solid reliability for intense gaming sessions and heavy AI PC workloads.
Equipped with a 16+1+2+1 power stage design (80A DrMOS) and enlarged VRM heatsinks, the board guarantees stable power delivery to handle next-gen CPUs. AI-powered technologies like AI Overclocking, AI Cooling II, AI Networking II, and AI Advisor make optimization effortless, while the unique NPU Boost function overclocks the Neural Processing Unit with a single click to accelerate AI workloads.
With DDR5 support up to 9066+ MT/s (OC) and DIMM Fit/DIMM Fit Pro tuning, plus 4 x M.2 slots (including PCIe 5.0 x4), the Z890-PRO WIFI is designed for speed. Connectivity is equally future-ready, featuring dual Thunderbolt™ 4 ports, front-panel USB 20Gbps Type-C® with 30W PD charging, Intel® 2.5Gb Ethernet, and Wi-Fi 7 with ASUS Q-Antenna.
Gamers will also benefit from immersive DTS Audio Processing powered by the Realtek ALC1220P codec, synchronized Aura Sync RGB lighting with Gen 2 ARGB headers, and extensive DIY-friendly features like Q-Release Slim, M.2 Q-Latch, BIOS FlashBack™, and SafeSlot. Backed by TUF reliability testing and compatibility with TUF Gaming Alliance components, the Z890-PRO WIFI offers unmatched stability and next-gen performance.
Features
Supports Intel® Core™ Ultra Processors (Series 2) with LGA1851 socket
Intel® Z890 chipset with PCIe® 5.0 expansion
16+1+2+1 power stages (80A DrMOS) with enlarged VRM heatsinks
AI Suite: AI Overclocking, AI Cooling II, AI Networking II, AI Advisor
NPU Boost BIOS feature for AI workload acceleration
DDR5 support up to 9066+ MT/s (OC) with AEMP III, DIMM Fit & DIMM Fit Pro
4 x M.2 slots (1 x PCIe 5.0, 3 x PCIe 4.0/SATA) + 4 x SATA 6Gb/s
Dual Thunderbolt™ 4 ports + Front USB 20Gbps Type-C® with 30W PD Fast Charge
Wi-Fi 7 with ASUS Q-Antenna + Intel® 2.5Gb Ethernet with TUF LANGuard
Realtek ALC1220P audio with DTS Audio Processing, premium capacitors, and optical S/PDIF
DIY enhancements: Q-Release Slim, M.2 Q-Release, Q-Slide, Q-Latch, BIOS FlashBack™, SafeSlot & SafeDIMM
Aura Sync RGB lighting with 3 x ARGB Gen 2 headers and edge lighting
Armoury Crate, TurboV Core, DriverHub, GlideX, DTS Audio Processing, and USB Wattage Watcher software
TUF durability: military-grade chokes/capacitors, stainless-steel I/O, ESD Guards, 8-layer PCB
Specifications
| Categories | Details |
|---|---|
| Model | TUF GAMING Z890-PRO WIFI |
| CPU Support | Intel® Core™ Ultra Processors (Series 2), Turbo Boost 2.0 & 3.0 |
| Chipset | Intel® Z890 |
| Memory | 4 x DIMM DDR5, up to 256GB, 9066+ MT/s (OC), Dual Channel, AEMP III, DIMM Fit / DIMM Fit Pro |
| Graphics Outputs | 1 x HDMI 2.1, 1 x DisplayPort 1.4, 2 x Thunderbolt™ 4 (DP/USB-C) |
| Expansion Slots | 1 x PCIe 5.0 x16 (SafeSlot), 1 x PCIe 4.0 x16 (x4), 1 x PCIe 4.0 x4, 2 x PCIe 4.0 x1 |
| Storage | 4 x M.2 (1 x PCIe 5.0 x4, 2 x PCIe 4.0 x4, 1 x PCIe 4.0 x4 & SATA), 4 x SATA 6Gb/s |
| Networking | Intel® 2.5Gb Ethernet, Wi-Fi 7 (2×2) with ASUS Q-Antenna, Bluetooth® 5.4 |
| USB (Rear I/O) | 2 x Thunderbolt™ 4 (USB-C), 6 x USB 10Gbps (Type-A) |
| USB (Front) | 1 x USB 20Gbps Type-C (30W PD), 1 x USB 5Gbps header (2 ports), 2 x USB 2.0 headers (4 ports) |
| Audio | Realtek ALC1220P 7.1 surround sound, DTS Audio Processing, Optical S/PDIF, premium capacitors |
| Cooling Headers | 1 x CPU Fan, 1 x CPU OPT, 1 x AIO Pump, 4 x Chassis Fans |
| Special Features | AI Suite (Overclocking, Cooling, Networking, Advisor), NPU Boost, M.2 Q-Latch, PCIe Q-Release Slim, BIOS FlashBack™, SafeSlot, SafeDIMM, Armoury Crate, Aura Sync RGB |
| Form Factor | ATX, 30.5 cm x 24.4 cm |
| OS Support | Windows 11 (22H2 & later, Wi-Fi 7 requires 24H2 or later) |
