Asus ROG THOR 850W Platinum II Fully Modular, 80 Plus Platinum Power Supply
This power supply is designed for users who want both performance and aesthetics, featuring top-tier components, efficient power delivery, and customizable lighting options. It is perfect for gaming enthusiasts and PC builders who demand both quality and style from their system.
Features
-
80 PLUS Platinum Certification: This certification ensures high energy efficiency, reducing power loss and keeping your system running efficiently.
-
850W Power Output: Ideal for mid- to high-end gaming PCs and workstations, offering reliable power for demanding components.
-
Fully Modular Design: Allows you to use only the cables you need, reducing cable clutter and improving airflow inside your case.
-
ROG Hybrid Fan Bearing Design: The 135mm fan features a durable dual ball bearing design, optimized for cooling efficiency and noise reduction.
-
OLED Power Display: An OLED screen on the power supply shows real-time power usage, providing a sleek way to monitor your system’s power consumption.
-
Aura Sync RGB Lighting: The power supply is equipped with customizable RGB lighting, allowing you to sync with other ROG Aura Sync-compatible components for a unified look.
-
High-End Japanese Capacitors: Built with premium capacitors, providing long-lasting reliability and stable power delivery.
-
0dB Technology: The fan operates in a completely silent mode under low to moderate loads, providing quiet performance when needed.
-
Enhanced Cooling: The advanced hybrid fan control adjusts fan speed for optimal cooling and noise levels, ensuring reliable performance even during high loads.
Specifications
| Model | ROG-THOR-850W-PLATINUM-II |
| Form Factor | ATX (Full Size) |
| Total Output Power | 850W |
| Efficiency Certification | 80 PLUS Platinum |
| AC Input Voltage Range | 100V – 240V AC |
| DC Output Voltages | +3.3V, +5V, +12V, -12V, +5Vsb |
| Maximum Load per Rail | +3.3V: 20A, +5V: 20A, +12V: 70.8A, -12V: 0.3A, +5Vsb: 3A |
| Combined Load | +3.3V & +5V: 120W, +12V: 850W, -12V: 3.6W, +5Vsb: 15W |
| Connectors Included | – Motherboard (24/20-pin): 1 – CPU (4+4-pin): 2 – PCIe (8-pin): 2 – PCIe (6+2-pin): 2 – SATA: 6 – Peripheral (4-pin): 4 |
| Cooling Fan | 135mm ROG Hybrid Fan with dual ball bearings |
| Fan Bearings | Dual ball bearings |
| 0dB Technology | Yes, fan shuts off below 40% load |
| RGB Lighting | Yes, Aura Sync compatible for customizable lighting effects |
| OLED Power Display | Real-time power usage display |
| Dimensions (L x W x H) | 150mm x 150mm x 86mm |
